SPECIFICATIONS
Product Name	CPI brand PP Pipes
Range	we offer a wide range of pipes as per the table below
Color	Grey
Where can be used	In Water treatment, Waste treatment, DeIonized Water, chemical Process Industry
Advantages	Good Corrosion resistance, High impact resistance, High thermal Ageing and Thermal forming resistance, excellent weldability

"CPI" Brand PP PIPES As Per DIN : 8077

PP ( POLY PROPYLENE )

POLY PROPYLENE - IS 4984:1995

Installation Method

Polypropylene pipe or fittings are joined to each other by heat fusion or with mechanical fittings. Plastics may be joined to other materials by means of compression fittings, flanges, or other qualified types of manufactured transition fittings. There are many types and styles of fittings available from which the user may choose. Each offers it's particular advantages and limitations for each joining situation the user may encounter. Contact with the various manufacturers is advisable for guidance in proper applications and styles available for joining as described in this document. There will be joining methods discussed in this document covering both large and small diameter pipe.

There are two types of heat fusion joints currently used in the industry.

• Butt Fusion
• Socket Fusion

Butt Fusion

The principle of heat fusion is to heat two surfaces to a designated temperature, then fuse them together by application of a sufficient force. this force causes the melted materials to flow and mix, thereby resulting in fusion. When fused accordingg to the pipe and/or fitting manufacturers' procedures, the joint area becomes as strong as or stronger than the pipe itself in both tensil and pressure properties. As soon as the joint cools to near ambient temperature, it is ready for handling.

The 6 steps involved in making a butt fusion joint are:
• Securely fasten the componets to be joined
• Face the pipe ends
• Align the pipe profile
• Melt the pipe interfaces
• Join the two profiles together
• Hold under pressure

Socket Fusion

This technique consists of siultaneously heatin both the external surface of the pipe and the internal surface of the socktet fitting untill the material reaches fusion temperature; inspecting the melt pattern; inseritng the pipe end into the socket; and holding it in place untill the joint cools. Figure 6.4 illustrates a typical socket fusion joint. Mechanical equipment is available and should be used for sizes larger than 2-inch diameter to attain the increased force required and to assist in alingnment.

Follow These general steps when performing socket fusion:
• Select the equipment
• square and prepare the pipe ends.
• Heat the parts
• Join the parts
• Allow to cool

PP Material use & characteristic

Polypropylene is suitable for use with foodstuffs, portable and ultra pure waters, as well as within the pharmaceutical and chemical industries. Polypropylene is adversely affected by UV radiation and requires insulation or a protective coating if installed outside.

• Environmental resistance to most organic and inorganic chemicals.
• Good material strength and fatigue resistance
• Operating temperature range -10 to 110°C (14 to 230°F)
• Fusion Welding
